- – 2.5 inch
- – SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
- – Samsung V-NAND 4bit MLC
- – Up to 560 MB/s Sequential Read Performance may vary based on system
- – Up to 530 MB/s Sequential Write Performance may vary based on system
Enhanced in every way
Achieving the maximum SATA interface limit of 560/530 MB/s sequential speeds, the 870 QVO features improved random speed and sustained performance compared to the previous 860 QVO. Intelligent TurboWrite accelerates write speeds and maintains long-term high performance with a larger variable buffer.
Enjoy max capacity
The 870 QVO is available in 1, 2, 4 and 8TB, and the 8TB model is by far the largest client SATA SSD. With the 870 QVO, users can now enjoy and thrive in the largest SSD computing environment ever.
Reliable and sustainable
The groundbreaking capacity of the 870 QVO doubles its reliability up to 2,880 TBW compared to the previous model 860 QVO and is backed by a limited warranty of 3 years. This formidable SSD provides further reliability with a refined ECC algorithm that enables a stable performance.
Upgrade with ease
Upgrading to the 870 QVO is made easy for anyone with a desktop PC or laptop that supports a standard 2.5-inch SATA form factor. Enjoying this terabyte SSD is as convenient as plugging in the 870 QVO into a SATA slot and letting the renewed migration software take care of the rest.
Samsung Magician software
Make your drive work like magic. The new and improved Samsung Magician 6.1 software will keep your SSD in check. You can easily manage your drive with a wide range of useful tools to keep up with the latest updates, monitor the drive’s health and status or even enhance its performance.
The world’s number one for flash memory
Experience the superior performance and reliability that you can only get from the world’s number one brand for flash memory since 2003. All firmware and components, including Samsung’s world-renowned DRAM and NAND, are produced in-house, allowing end-to-end integration for quality you can trust.
General Feature
- Application Client PCs
- Capacity 4,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
- Form Factor 2.5 inch
- Interface SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
- Dimension (W x H x D) 100 X 69.85 X 6.8 (mm)
- Weight Apporx. 54.0 g Weight
- Storage Memory Samsung V-NAND 4bit MLC
- Controller Samsung MKX Controller
- Cache Memory Samsung 4 GB Low Power DDR4 SDRAM
Special Feature
- TRIM Support TRIM Supported
- S.M.A.R.T Support S.M.A.R.T Supported
- GC (Garbage Collection) Auto Garbage Collection Algorithm
- Encryption Support AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)
- WWN Support World Wide Name supported
- Device Sleep Mode Support Yes
Performance
- Sequential Read Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
- Sequential Write Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
- Random Read (4 KB, QD32) Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
- Random Write (4 KB, QD32) Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
- Random Read (4 KB, QD1) Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
- Random Write (4 KB, QD1) Up to 35,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Environment
- Average Power Consumption (System Level) Average: 3.2 W *Maximum: 5.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
- Power consumption (Idle) Max. 35 mW * Actual power consumption may vary depending on system hardware & configuration
- Allowable Voltage 5V ± 5% Allowable voltage
- Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
- Operating Temperature 0 – 70 ℃ Operating Temperature
- Shock 1,500 G & 0.5 ms (Half sine)
Accessories
- Installation Kit Not Available
Software
- Management SW Magician Software for SSD management
Warranty
- 3 Years Limited Warranty or 1,440 TBW Limited Warranty
