Advantech 7″ WVGA CORTEX A8 256MB WCE6.0
R12,100 Incl VAT
Pay R11,737 When paying via EFT at checkout.
In stock with Supplier
Calculate shipping price
Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.
0
People watching this product now!
Description
WOP-3070T-C4AE
Description
With brand-new ID design, the WebOP-3070T provides stringent standards required in the automation market. Advantech offers the WebOP-3070T with Cortex™-A8 processor which consumes minimum power without sacrificing performance. The WebOP-3070T supports a variety of LCD sizes from 4.3” to 15” for different applications involving the use of PLCs, motion/thermal controllers, inverters and sensors. It’s also provided with a wide operating temperature range to fulfill the requirements of harsh environments. The built-in Microsoft® WinCE 6.0 OS platform which bundles WebOP Designer lets the WebOP-3070T becomes a control HMI solution for flexible system integration.
Specification
WOP-3070T-C4AE Specs
| Communications/CAN | Terminal Plug 2-Pin |
| Communications/COM1 | RS-232/422/485 (DB9 Male) |
| Communications/COM2 | RS-422/485 (Terminal Plug 4-Pin) |
| Communications/COM3 | RS-485 (Terminal Plug 2-Pin) |
| Communications/Ethernet | 10/100-BaseT |
| Display/Size | 7″ |
| Environment/Humidity (Operating) | 10 ~ 90% RH @ 40°C, non-condensing |
| Environment/Ingress Protection | Front panel: IP66 |
| Environment/Temperature (Operating) | -20 ~ 60°C (-4 ~ 140°F) |
| Environment/Temperature (Storage) | -30 ~ 70°C (-22 ~ 158°F) |
| Environment/Vibration Protection | Operating, radom vibration 1 Grms (5 ~ 500 Hz) |
| General/Certifications | BSMI, CCC, CE, FCC Class A, UL |
| General/Cut-out Dimensions | 192 x 138.5 mm (7.56″ x 5.45″) |
| General/Dimensions | 203.4 x 150 x 43.7 mm (8.01″ x 5.91″ x 1.72″) |
| General/Enclosure Housing | PC + ABS |
| General/Mounting | Panel |
| General/OS Support | Microsoft® Windows CE 6.0 |
| General/Power Consumption | 7W (Typical) |
| General/Power Input | 24VDC ±10% |
| General/Weight (Net) | 1 Kg (2.20 lbs) |
| LCD Display/Backlight Life | LED, 50,000 |
| LCD Display/Contrast Ratio | 700:1 |
| LCD Display/Dimming | Adjustable by touch panel |
| LCD Display/Display Type | WVGA TFT LCD |
| LCD Display/Luminance (cd/m2) | 500 |
| LCD Display/Max. Colors | 64K |
| LCD Display/Max. Resolution | 800 x 480 |
| LCD Display/Viewing Angle (H/V°) | 140/120 |
| System Hardware/Battery Backup Memory | FRAM 128KB |
| System Hardware/CPU | RISC 32 bits, 600 MHz (ARM® Cortex™-A8) |
| System Hardware/Flash Memory | DDR2 256MB on board |
| System Hardware/Power-On LED | Yes |
| System Hardware/Storage | 512MB on board SLC type |
| Touchscreen/Lifespan | 36 million touches at 8mm-diameter finger point |
| Touchscreen/Light Transmission | Transmission Above 80% |
| Touchscreen/Resolution | Linearity |
| Touchscreen/Touch Type | 5-wire, analog resistive |
