- GPU: Boost Clock: Up to 2360MHz
- Memory: 16GB/256 bit DDR6. 16 Gbps Effective
- Stream Processors: 4608
- RDNA™ 2 Architecture
- Ray Accelerator: 72
- ARGB Fan
GPU | Radeon™ RX 6800 Graphics |
7nm GPU | |
RDNA 2 Architecture | |
Engine Clock | Boost Clock: Up to 2360 MHz |
Game Clock: Up to 2110 MHz | |
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary. | |
Stream Processors | 4608 |
Infinity Cache | 128MB |
Ray Accelerators | 72 |
Memory Size/Bus | 16GB GDDR6 |
Memory Clock | 16 Gbps Effective |
Displays | Maximum 4 Displays |
Resolution | HDMI™: 7680×4320 |
DisplayPort1.4: 7680×4320 | |
USB-C: 7680×4320 | |
Interface | PCI-Express 4.0 |
Output | 1x HDMI |
2x DisplayPort | |
1x USB-C | |
BIOS Support | Dual UEFI |
Game Index | 4K |
Sapphire Features | Dual BIOS |
Max Boost | |
TriXX Software Switch | |
Premium Digital Power Design | |
Fuse Protection | |
Tri-X Cooling Technology | |
Intelligent Fan Control | |
Precision Fan Control | |
Backplate with ARGB | |
Two-Ball Bearing Fans | |
Hybrid Fan Blade | |
Wave Fin Design | |
V Shape Fin Design for GPU Cooling | |
Integrated Cooling Module | |
K6.5 Memory Pad | |
TriXX Supported | |
Fan Check | |
Fan Quick Connect | |
TriXX Boost | |
NITRO Glow | |
External RGB LED MB Synchronization | |
ARGB Fans | |
AMD Features | AMD RDNA™ 2 Gaming Architecture |
DirectX® 12 Ultimate | |
Hardware Raytracing | |
7nm GPU | |
GDDR6 Memory | |
PCI® Express 4.0 Support | |
AMD FreeSync™ Technology | |
DisplayPort™ 1.4 with DSC | |
HDMI™ 2.1 VRR | |
Video Streaming up to 8K | |
Radeon™ VR Ready Premium | |
AMD FidelityFX | |
Radeon™ Image Sharpening | |
Radeon™ Anti-Lag | |
Radeon™ Software | |
Game Driver Optimizations | |
High Performance 4K Gaming | |
Cooling | 3 Fans |
Form Factor | 2.7 slot, ATX |
Dimension: 310(L)X 134.3(W)X 55.3 (H)mm | |
Power Consumption | 350W |
OS | Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required |
*Does not support all features including but not limited to Hardware Raytracing | |
System Requirement | Minimum 850 Watt Power Supply |
2 x 8-pin Power Connector. | |
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. | |
Minimum 8GB of system memory. 16GB recommended. |
