Form factor M.2 2280/mSATA
Interface SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)
Capacities1 120GB, 240GB, 480GB, 960GB, 1.92TB
Controller Marvell 88SS1074 Controller
NAND 3D TLC
Encryption Encryption Support (AES 256-bit)
Sequential Read/Write2 120GB — up to 520/320MB/s
240GB — up to 520/500MB/s
480GB — up to 520/500MB/s
960GB — up to 520/500MB/s
1.92TB — up to 520/500MB/s
Maximum 4K Read/Write2 120GB — up to 79,000/18,000 IOPS
240GB — up to 79,000/25,000 IOPS
480GB — up to 79,000/35,000 IOPS
960GB — up to 79,000/45,000 IOPS
1.92TB — up to 79,000/50,000 IOPS
Power Consumption 0.195W Idle / 0.5W Avg / 1.17W (MAX) Read / 2.32 W (MAX) Write
Dimensions 100.1mm x 69.85mm x 7mm (2.5”)
80mm x 22mm x 3.5mm (M.2)
50.8mm x 29.85mm x 4.85mm (mSATA)
Operating temperature 0°C~70°C
Storage temperature -40°C~85°C
Weight 120GB–480GB — 41g (2.5”)
960GB — 57g (2.5”)
1.92TB — 52g (2.5”)
120GB — 6.6g (M.2)
240GB — 6.7g (M.2)
480GB — 7.7g (M.2)
960GB — 7.8g (M.2)
120GB — 6.2g (mSATA)
240GB –480GB — 6.7g (mSATA)
Vibration operating 2.17G Peak (7–800Hz)
Vibration non-operating 20G Peak (10–2000Hz)
Life expectancy 1 million hours MTBF
Warranty/support3 Limited 5-year warranty with free technical support
Total Bytes Written (TBW)4 120GB — 60TB
240GB — 100TB
480GB — 200TB
960GB — 480TB
1.92TB — 800TB
3 – 5 Working days before Dispatch
