- Supports AMD Ryzenā¢ 5000 Series/ 3rd Gen Ryzenā¢ and 3rd Gen Ryzenā¢ with Radeonā¢ Graphics Processors
- Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs
- 5+3 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETs
- Ultra Durableā¢ PCIe 4.0 Ready x16 Slot
- Dual Ultra-FastĀ NVMe PCIe 4.0/3.0 M.2 Connectors
- High Quality Audio Capacitors and Audio Noise Guard for Ultimate Audio Quality
- GIGABYTE Exclusive 8118 Gaming GbE LAN
- Rear HDMI & DVI Support
- RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips
- Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
- Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
- Anti-Sulfur Resistors Design
Specifications | |
---|---|
CPU | AMD Socket AM4, support for: AMD Ryzenā¢ 5000 Series/ 3rd Gen Ryzenā¢ and 3rd Gen Ryzenā¢ with Radeonā¢ Graphics Processors |
(Please refer “CPU Support List” for more information.) | |
Chipset | AMD B550 |
Memory | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory |
3rd Gen AMD Ryzenā¢ Processors: | |
Support for DDR4 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules | |
3rd Gen AMD Ryzenā¢ with Radeonā¢ Graphics processors: | |
Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules | |
Dual channel memory architecture | |
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules | |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Support for Extreme Memory Profile (XMP) memory modules | |
(Please refer “Memory Support List” for more information.) | |
Onboard Graphics | Integrated in the 3rd Generation AMD Ryzenā¢ with Radeonā¢ Graphics processors: |
1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz | |
* The DVI-D port does not support D-Sub connection by adapter. | |
1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz | |
* Support for HDMI 2.1 version, HDCP 2.3, and HDR. | |
Maximum shared memory of 16 GB | |
Audio | RealtekĀ® ALC887 codec |
High Definition Audio | |
2/4/5.1/7.1-channel | |
* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE’s website for details on configuring the audio software. | |
LAN | RealtekĀ® GbE LAN chip (1000 Mbit/100 Mbit) |
Expansion Slots | 1ā x PCI Express x16 slot (PCIEX16), integrated in the CPU: |
3rd Generation AMD Ryzenā¢ processors support PCIe 4.0 x16 mode | |
3rd Generation AMD Ryzenā¢ with Radeonā¢ Graphics processors support PCIe 3.0 x16 mode | |
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset: | |
Supporting PCIe 3.0 x4 mode | |
1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset: | |
Supporting PCIe 3.0 x1 mode | |
Storage Interface | 1ā x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: |
3rd Generation AMD Ryzenā¢ processors support SATA and PCIe 4.0 x4/x2 SSDs | |
3rd Generation AMD Ryzenā¢ with Radeonā¢ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs | |
1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs: | |
Supporting SATA and PCIe 3.0 x2 SSDs | |
4 x SATA 6Gb/s connectors, integrated in the Chipset: | |
Support for RAID 0, RAID 1, and RAID 10 | |
USB | CPU: |
4 x USB 3.2 Gen 1 ports on the back panel | |
Chipset: | |
2 x USB 3.2 Gen 1 ports available through the internal USB header | |
6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) | |
Internal I/O Connectors | 1 x 24-pin ATX main power connector |
1 x 8-pin ATX 12V power connector | |
1 x CPU fan header | |
2 x system fan headers | |
2 x addressable LED strip headers | |
2 x RGB LED strip headers | |
1 x CPU cooler LED strip/RGB LED strip header | |
2 x M.2 Socket 3 connectors | |
4 x SATA 6Gb/s connectors | |
1 x front panel header | |
1 x front panel audio header | |
1 x USB 3.2 Gen 1 header | |
1 x USB 2.0/1.1 header | |
1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) | |
1 x serial port header | |
1 x Clear CMOS jumper | |
1 x Q-Flash Plus button | |
Back Panel Connectors | 1 x PS/2 keyboard/mouse port |
1 x DVI-D port | |
1 x HDMI port | |
4 x USB 3.2 Gen 1 ports | |
4 x USB 2.0/1.1 ports | |
1 x RJ-45 port | |
3 x audio jacks | |
I/O Controller | iTEĀ® I/O Controller Chip |
H/W Monitoring | Voltage detection |
Temperature detection | |
Fan speed detection | |
Overheating warning | |
Fan fail warning | |
Fan speed control | |
* Whether the fan speed control function is supported will depend on the cooler you install. | |
BIOS | 1 x 256 Mbit flash |
Use of licensed AMI UEFI BIOS | |
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
Unique Features | Support for APP Center |
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | |
@BIOS | |
EasyTune | |
Fast Boot | |
Game Boost | |
ON/OFF Charge | |
RGB Fusion | |
Smart Backup | |
System Information Viewer | |
Support for Q-Flash Plus | |
Support for Q-Flash | |
Support for Xpress Install | |
Bundled Software | NortonĀ® Internet Security (OEM version) |
RealtekĀ® 8118 Gaming LAN Bandwidth Control Utility | |
Operating System | Support for Windows 10 64-bit |
Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
Remark | Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors’ website or 3rd party website. |
Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website. |
