- Form Factor: M.2 2280
- Interface: PCI-Express 3.0 x4, NVMe 1.3
- Total Capacity: 256GB*
- Warranty: Limited 5-years
- Sequential Read Speed : up to 3100 MB/s**
- Sequential Write speed : up to 1050 MB/s**
- TRIM & S.M.A.R.T supported
- AES 256 supported
*Note: 1GB = 1 billion bytes. Actual useable capacity may vary.
**Speeds based on internal testing. Actual performance may vary.
![](https://www.gigabyte.com/FileUpload/Global/KeyFeature/1094/images/rgb2-logo.png)
Capacity* | Model | Sequential Read MB/s** | Sequential Write MB/s** | Random Read IOPS** | Random Write IOPS** |
---|---|---|---|---|---|
256GB | AORUS RGB M.2 NVMe SSD 256GB
( GP-ASM2NE2256GTTDR )
|
3100 MB/s | 1050 MB/s | 180K | 240K |
512GB | AORUS RGB M.2 NVMe SSD 512GB
( GP-ASM2NE2512GTTDR )
|
3480 MB/s | 2000 MB/s | 360K | 440K |
** Speeds based on internal testing. Real performance may vary by models.
Interface | PCI-Express 3.0 x4, NVMe 1.3 |
Form Factor | M.2 2280 |
Warranty | Limited 5-years or 380TBW |
NAND | 3āD TLC NAND FLASH |
External DDR Cache | 5ā12MB |
Sequential Read speed | Up to 3100 MB/s |
Sequential Write speed | Up to 1050 MB/s |
Random Read IOPS | 1ā80K |
Random Write IOPS | 2ā40K |
Mean time between failure (MTBF) | 1ā.8 million hours |
Power Consumption (Active) | Average : R : 5085mW ; W : 3285mW |
Power Consumption (Idle) | 2ā72mW |
Temperature (Operating) | 0āĀ°C to 70Ā°C |
Temperature (Storage) | -40Ā°C to 85Ā°C |
Note | |
* Test system configuration: configuration may vary by models, we will choose the latest platform for verification. | |
* Performance may vary based on SSD’s firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark v.5.1.2 and I0meter 1.1.0. | |
* Speeds based on internal testing. Actual performance may vary. | |
* TBW (Terabyte Written):Terabytes Written” is the total amount of data that can be written into an SSD before it is likely to fail. | |
* 1GB = 1 billion bytes. Actual useable capacity may vary. | |
* 5 years or 380 TBW, whichever comes first. |
