Specifications in detail

General Specifications

• Machine Type
  Mono Laser All-In-One
• Available Functions
  Print, Copy, Scan and Fax

Print Specifications

• Print Speed
  Single sided : Up to 40 ppm (A4); Up to 65.4 ppm(A5-Landscape)
  Double sided : Up to 33.6 ipm (A4)
• Printing Method
  Monochrome laser beam printing
• Print Resolution
  Up to 1200 x 1200 dpi
• Warm-up Time
  Approx. 14 seconds or less from power on
• First-Print-Out Time
  Approx: 5.0 seconds or less
• Printer Languages
  UFRII, PCL 5e¹, PCL6, Adobe® PostScript3
• Fonts
  45 PCL fonts
  136 PostScript fonts
• Print Margins
  5 mm-top, bottom, left and right
  10 mm-top, bottom, left and right (Envelope)
• Toner Saver Mode
  Yes
• Advanced Printing Features
  Encrypted Secure Print
  Secure Print
  Print from USB memory key (JPEG/TIFF/PDF)
  Print from Cloud (Dropbox, GoogleDrive, OneDrive) (PDF/JPEG)
  Microsoft Universal Print
  iOS: AirPrint, Canon PRINT Business app
  Android; Mopria certified, Canon PRINT Business app, Canon Print Service Plug-in²

Copy Specifications

• Copy Speed
  Single sided (A4): Up to 40 ppm
  Double sided (A4): Up to 33.6 ipm
• First-Copy-Out Time
  Approx. 6.1 seconds or less
• Copy Resolution
  Up to 600 x 600 dpi
• Copy Modes
  Text, Text/Photo (Default), Text/Photo (High Quality), Photo
• Double Sided Copying
  2-sided to 2-sided (Automatic)
• Multiple Copies
  Up to 999 copies
• Reduction / Enlargement
  25-400% in 1% increments
• Other Features
  Frame Erase, Collate, 2 on 1, 4 on 1, ID card copy

Scan Specifications

• Standard Type
  Colour
• Scan Resolution
  Optical: Up to 600 x 600 dpi
  Enhanced: Up to 9600 x 9600 dpi
• Scan Speed
  Single sided mono: 50ipm (300x300dpi)
  Single sided colour: 40ipm (300x300dpi)
  Double sided mono: 100ipm (300x300dpi)
  Double sided colour: 80ipm (300x300dpi)
  Single sided mono: 40ipm (300x600dpi)
  Single sided colour: 20ipm (300x600dpi)
  Double sided mono: 80ipm (300x600dpi)
  Double sided colour: 40ipm (300x600dpi)
• Colour Scanning Depth
  24 bit/24 bit (input/output)
• Greyscales
  256 levels
• Compatibility
  TWAIN , WIA, ICA
• Maximum Scan Width
  216mm
• Scan to E-mail
  TIFF/JPEG/PDF/Compact PDF/Searchable PDF
• Scan to PC
  TIFF/JPEG/PDF/Compact PDF/Searchable PDF
• Scan to USB Memory Key
  TIFF/JPEG/PDF/Compact PDF/Searchable PDF
• Scan to FTP
  TIFF/JPEG/PDF/Compact PDF/Searchable PDF
• Scan to Cloud
  TIFF/JPEG/PDF/PNG³
• iFAX
  ITU-T.37

Fax Specifications

• Modem Speed
  33.6 Kbps (Up to 3 seconds/page)
• Receive Mode
  Fax only, Fax/Tel Auto Switch, Answer Mode, Manual
• Fax Resolution
  Standard: 200 x 100 dpi
  Fine: 200 x 200 dpi
  Super fine: 200 x 400 dpi
  Ultra fine: 400 x 400 dpi
• Fax Memory
  Up to 512 pages
• Speed Dials
  Up to 281 dials
• Group Dials/Destinations
  Max. 299 dials / Max. 299 destinations
• Sequential Broadcast
  Max. 310 destinations
• Memory Backup
  Permanent fax memory backup (Backup with flash memory)
• Double Sided Faxing
  Yes (Transmit and Receive)
• Other Features
  Sender’s Name (TTI), Direct Send, TX Report, Sequential Broadcasting

Media Handling

• Scanner Type
  Platen, 2-sided ADF (single pass)
• Paper Input (Standard)
  250-sheet cassette
  100-sheet multi-purpose tray
  50-sheet ADF
• Paper Input (Option)
  550-sheet cassette
• Maximum Paper Input Capacity
  900 sheets
• Paper Output
  150-sheet
• Media Types
  Plain paper, Recycled paper, Heavy Paper, Thin paper, Label, Post card, Envelope
• Media Sizes
  Cassette (Standard and optional):
  A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Custom sizes: Min. 105 x 148 mm Max. 216.0 x 355.6 mm.

  Multi-purpose tray:
  A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Indexcard, Envelope (COM10, Monarch, C5, DL), Custom sizes: Min 76.2 x 127 mm Max. 216.0 x 355.6 mm.

  ADF:
  A4, A5, A6, B5, Legal, Letter, Statement, Custom sizes: Min. 48 x 85.0 mm Max 216 x 355.6 mm

• Media Weights
  Cassette (standard and optional): 60 to 120 g/m²
  Multi-purpose tray: 60 to 199 g/m²
  ADF: 60 to 120 g/m²
• Double Sided Printing
  A4, Legal, Letter, OFFICIO, B-OFFICIO, M-OFFICIO, GLGL, Foolscap
  Custom size – Min. 210 x 279.4 mm Max. 216.0 x 355.6 mm
  60 to 120 g/m²

Interface & Software

• Interface Type
  USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T, Wireless 802.11b/g/n, Wireless Direct Connection
• Operating System Compatibility
  Windows® 11 / Windows® 10 / Server® 2022 / Server® 2019 / Server® 2016 / Server® 2012R2 / Server® 2012
  Mac OS X version 10.13 & up
  Linux⁴
• Network Protocol
  Print:
  TCP/IP (LPD/Port9100/IPP/IPPS/WSD)
  Scan:
  Push Scan: File: FTP (TCP/IP), SMB3.0 (TCP/IP)
  E-mail/I-Fax: SMTP (send), POP3 (receive)
  Pull Scan: TCP/IP

  Management:
  SNMPv1, SNMPv3 (IPv4,IPv6)

  Security:
  TLS1.3, IPSec, IP address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
  Security (wireless):
  Infrastructure Mode:
  WEP(64/128 bit), WPA-PSK(TKIP/AES), WPA2-PSK(TKIP/AES), WPA-EAP(AES), WPA2-EAP(AES)
  Access Point Mode:
  WPA2-PSK(AES)

• Software and Printer Management
  MF Scan Utility,
  Remote User Interface (RUI),
  Department ID Management,
  Toner Status Tool,
  iW Enterprise Management Console: Server-based software for centralised management of a fleet of devices
  eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics
  Application Library

General Features

• Recommended Monthly Print Volume
  750 – 4,000 pages per month
• Duty Cycle
  Max. 80,000 pages per month⁵
• Processor Speed
  1200MHz
• Memory
  1GB
• Storage
  4GB eMMC
• Control Panel
  12.7 cm LCD Colour Touch Screen
• Dimensions with Trays (W x D x H)
  420 mm x 460 mm x 375 mm
• Installation Space (W x D x H)
  689 mm x 1,081 mm x 824 mm
• Weight
  Approx. 16.3 Kg
• Operating Environment
  Temperature: 10 to 30ºC (50 to 86ºF)
  Humidity: 20 to 80% RH (no condensation)
• Power Source
  220-240V(±10%) 50/60Hz (±2Hz)
• Power Consumption
  Maximum: Approx. 1,280 W
  Active printing: Approx. 480W
  Standby: Approx. 8 W
  Sleep mode: Approx. 0.9 W
  Typical Electricity Consumption (TEC): 0.32 kWh/week (230V)
  For detailed information relating to Lot26 regulation, please go to: http://www.canon-europe.com/For_Work/Lot26/index.aspx
• Noise Levels
  Sound Pressure⁶:
  Active: 53dB
  Standby: Inaudible⁷

  Sound Power⁸:
  Active: Duplex 68dB / Simplex 67dB
  Standby: Inaudible⁹

Consumables

• Cartridges
  Cartridge 070 (3,000 pages)
  Cartridge 070H (10,200 pages)

Accessories & Options

• Items
  CST.Feeding Module-AH1 (550-sheet cassette)
