Specifications in detail

General Specifications

• Machine Type
  Colour laser
• Available Functions
  Print

Print Specifications

• Print Speed
  Single sided: Up to 33 ppm (A4)
  Single sided: Up to 60 ppm(A5-Landscape)
  Double sided: Up to 29.5 ipm (A4)
• Printing Method
  Colour laser beam printing
• Print Resolution
  Up to 1200 x 1200 dpi
• Warm-up Time
  Approx. 19.4 seconds or less from power on
• First-Print-Out Time
  Colour approx.: 7.1 seconds or less
  Mono approx.: 7.1 seconds or less
• Printer Languages
  UFRII, PCL5c*, PCL6, Adobe® PostScript*

  *Commands supported only. Third party driver or direct printing from application required.

• Fonts
  45 PCL fonts, 136 PS fonts
• Print Margins
  5 mm-top, bottom, left and right
• Advanced Printing Features
  Encrypted Secure Print
  Secure Print
  Print from USB memory key (JPEG/TIFF/PDF)
  Microsoft Universal Print support
  iOS: AirPrint, Canon PRINT Business app
  Android; Mopria certified, Canon Print Service Plug-in, Canon PRINT Business app

Media Handling

• Paper Input (Standard)
  250-sheet cassette
  50-sheet multi-purpose tray
• Paper Input (Option)
  550-sheet cassette
• Maximum Paper Input Capacity
  850 sheets
• Paper Output
  150-sheet
• Media Types
  Plain paper, Recycled paper, Heavy Paper, Thin paper, Colour paper, Coated paper, Pre-punched, Label, Post card, Envelope
• Media Sizes
  Cassette (Standard):
  A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Envelop (COM10, DL, C5, Monarch), Custom sizes: Min. 98 x 148 mm Max. 216.0 x 356.0 mm.

  Multi-purpose tray:
  A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelope (COM10, DL, C5, Monarch), Custom sizes: Min 76 x 127 mm Max. 216.0 x 356.0 mm.

  Cassette (Optional):
  A4, A5, A5 (Landscape), A6, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Custom sizes: Min. 100 x 148 mm Max. 216.0 x 356.0 mm.

• Media Weights
  Cassette (standard and optional): 60 to 163 g/m² (Up to 200 g/m² with Coated paper)
  Multi-purpose tray: 60 to 176 g/m² (Up to 200 g/m² with Coated paper)
• Double Sided Printing
  Automatic
  Cassette:
  A4, A5, B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K

Interface & Software

• Interface Type
  USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T, Wireless 802.11b/g/n, Wireless Direct Connection
• Operating System Compatibility
  Windows® 11 / Windows® 10 / Windows® 8.1 / Server® 2022 / Server® 2019 / Server® 2016 / Server® 2012R2 / Server® 2012
  Mac OS X version 10.12 & up
  Linux*

  *Web distribution only

• Network Protocol
  Print:
  TCP/IP (LPD/Port9100/IPP/IPPS/WSD)

  Management:
  SNMPv1, SNMPv3 (IPv4,IPv6)

  Security :
  TLS1.3, IPSec, IP/Mac address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
  Security (wireless):
  Infrastructure Mode:
  WEP(64/128 bit), WPA-PSK(TKIP/AES), WPA2-PSK(TKIP/AES), WAP2-EAP(AEP)
  Access Point Mode:
  WPA2-PSK(AES)

• Software and Printer Management
  Remote User Interface (RUI),
  Department ID Management,
  Toner Status Tool,
  iW Enterprise Management Console: Server-based software for centralised management of a fleet of devices
  eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics.

General Features

• Recommended Monthly Print Volume
  750 – 4,000 pages per month
• Duty Cycle
  Max. 50,000 pages per month*

  *Duty cycle is defined as the maximum number of printed pages for a single peak month. Any usage above the recommended duty cycle may decrease the life of the product

• Processor Speed
  1200MHz x 2
• Memory
  1GB
• Control Panel
  5 Line LCD, 3 LED (Job, Error, Energy saver), Buttons, 10-key numeric keypad
• Dimensions with Trays (W x D x H)
  425 mm x 427 mm x 300 mm
• Weight
  Approx. 17.1 kg
• Operating Environment
  Temperature: 10 to 30ºC (50 to 86ºF)
  Humidity 20 to 80% RH (no condensation)
• Power Source
  220-240V (±10%) 50/60Hz (±2Hz)
• Power Consumption
  Maximum: Approx. 1,380W or less
  Active printing: Approx. 700 W
  Standby: Approx. 24.0W or less
  Sleep: Approx. 1.0 W or less
  Typical Electricity Consumption (TEC): 0.31 kWh/week*
  For detailed information relating to Lot26 regulation, please go to: http://www.canon-europe.com/For_Work/Lot26/

  *As per US ENERGY STAR® version3.0

• Noise Levels
  Sound power*
  Active: 65dB or less
  Standby: 36dB or less

  Sound pressure*
  Active: Simplex 51dB (CL)) / 50 dB (BW)
  Duplex 51dB (CL) / 50dB (BW)
  Standby: 25 dB

  *Declared noise emission in accordance with ISO 7779.
  Based on ISO9296, below figure is different.
  Active: 62dB or less

Consumables

• Cartridges
  Cartridge 069 Black (2,100 pages *)**
  Cartridge 069H Black (7,600 pages *)**
  Cartridge 069 Cyan (1,900 pages *)**
  Cartridge 069H Cyan (5,500 pages *)**
  Cartridge 069 Magenta (1,900 pages *)**
  Cartridge 069H Magenta (5,500 pages *)**
  Cartridge 069 Yellow (1,900 pages *)**
  Cartridge 069H Yellow (5,500 pages *)**

  *Based on ISO/IEC 19798
  **Printer ships with Black: 1.200 pages, C/M/Y: 1,100 pages starter cartridges

Accessories & Options

• Items
  PAPER FEEDER PF-K1 (550-sheet cassette)
