Asus ROG Strix X570
-I Gaming – End of Life
SKU / Product is End of Life
Pay R0 When paying via EFT at checkout.
ROG Strix X570-I Gaming
ROG Strix X570-I Gaming rises above the rest to deliver incredible power and undeniable style for your small form factor gaming build. With support for the latest AMD Ryzen processors, ROG Strix X570-I Gaming is primed to deliver maximum gaming performance, while its revolutionary miniature active cooling design efficiently works to keep temperatures down. Coupled with HDMI 2.0 and DisplayPort 1.4 for ultra-high-resolution video output, ultrafast next-generation wireless networking and PCIe 4.0 connectivity, ROG Strix X570-I Gaming is a compact gaming powerhouse.
AMD X570 mini-ITX Gaming motherboard with PCIe 4.0, Aura Sync RGB, Intel Gigabit Ethernet, Wi-Fi 6 (802.11ax), dual M.2 with heatsink, HDMI 2.0, DisplayPort 1.4, SATA 6Gb/s, and USB 3.2
- AMD AM4 socket: Ready for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series desktop processors; also supports up to two M.2 drives and features USB 3.2 Gen 2 and AMD StoreMI to maximize connectivity and speed
- Aura Sync RGB: ASUS-exclusive Aura Sync RGB lighting, including RGB header and addressable Gen 2 header
- Optimal Power Solution: 8+2 power stages with a ProCool II power connector, alloy chokes and durable capacitors to support multi-core processors
- Comprehensive cooling design: VRM and chipset heatsinks add mass to help absorb more heat and feature miniature fans, an embedded chipset heatpipe, an M.2 heatsink and an aluminum backplate with cyber-text pattern
- Gaming connectivity: Supports PCIe 4.0, HDMI 2.0 and DisplayPort 1.4 and features dual M.2 and USB 3.2 Type-A and Type-C connectors
- Gaming networking: Intel Gigabit Ethernet with ASUS LANGuard, Wi-Fi 6 (802.11ax) with MU-MIMO support, and gateway teaming via GameFirst V
- 5-Way Optimization: Automated system-wide tuning, providing overclocking and cooling profiles tailor made for your rig
- Gaming audio: High-fidelity audio with SupremeFX S1220A, DTS® Sound Unbound and Sonic Studio III to draw you deeper into the action
- Gamer’s Guardian: ASUS SafeSlot and premium components for maximum endurance
| Chipset | AMD X570 |
| CPU Socket | AM4 |
| USB | 4 x USB 3.1 / USB 3.2 Gen 1 Type-A 3 x USB 3.1 / USB 3.2 Gen 2 Type-A 1 x USB 3.1 / USB 3.2 Gen 2 Type-C |
| Display | 1 x HDMI 2.0 1 x DisplayPort 1.4 |
| Audio | 3 x 3.5 mm |
| Ethernet / Controller | 1 x Intel I211-AT Gigabit |
| Wi-Fi Antenna | 2 x Connector |
| Memory Slots | 2 x 288-Pin |
| Memory Support | DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3400, 3466, 3600, 3800, 4000, 4133, 4266, 4400, 4600, 4800 MHz |
| Maximum Capacity | 64 GB |
| Channel Architecture | Dual Channel |
| ECC Support | Non-ECC Unbuffered |
| SATA | 4 x SATA III |
| M.2 | 2 x M Key 2242, 2260, 2280 (PCIe 4.0 x4) |
| U.2 | None |
| Optane Memory Support | No |
| RAID Support | RAID 0, 1, 10 |
| Expansion Slots | 1 x PCIe 4.0 x16 (x16 mode) |
| USB | 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port) 1 x USB 2.0 Header (Supports 2 USB Type-A Port) |
| Multi-GPU Support | None |
| Air Cooling | 1 x 4-Pin CPU 1 x 4-Pin System 2 x 4-Pin Assistant 1 x Thermal Sensor |
| Liquid Cooling | 1 x 4-Pin Pump |
| Power Connectors | 1 x 24-Pin Mainboard 1 x 8-Pin CPU |
| Security | TPM Module |
| LED Header | 2 x RGB |
| Audio | 1 x Speaker |
| Diagnostics | Clear CMOS |
| ROM | 256 Mb |
| I/O Connection Headers | AAFP |
| Audio Codec | SupremeFX S1220A (8-Channel) |
| Bluetooth | 5.0 |
| Wi-Fi | Wi-Fi 6 (802.11ax) (MU-MIMO) |
| Supported Operating Systems | Windows 10 (64-Bit) |
| Form Factor | Mini-ITX |
| Dimensions | 6.69 x 6.69″ / 17 x 17 cm |
| Weight | 1 kg |
|---|---|
| Dimensions | 22.9 × 18.4 × 9.5 cm |
| Brand |
Asus |
| Socket |
AM4 |
| CPU Support |
Ryzen 2000 Series ,Ryzen 3000 Series ,Ryzen 4000 Series ,Ryzen 5000 Series |
| Chipset Manufacture |
AMD |
| Chipset Model |
X570 |
| Form Factor |
Mini ITX |
| Memory Slots Available |
2 Slots |
| On-Board WiFi |
Yes |
| Windows Compatibility |
Windows 10 ,Windows 11 ( Possibly Requires TPM ) |
