Transcend PCIe SSD 220S – 512GB

R3,800 Incl VAT

Pay R3,686 When paying via EFT at checkout.

In stock with Supplier

Calculate shipping price

Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.



13 People watching this product now!
SKU: TS512GMTE220S Category: Tags: , , , ,
Description

Appearance

Dimensions80 mm x 22 mm x 3.58 mm (3.15″ x 0.87″ x 0.14″)
Weight10 g (0.35 oz)
M.2 Type
  • 2280-D2-M (Double-sided)

Interface

Bus Interface
  • NVMe PCIe Gen3 x4

Storage

Flash Type
  • 3D NAND flash
Capacity
  • 256 GB/
  • 512 GB/
  • 1 TB/
  • 2 TB

Operating Environment

Operating Temperature0°C (32°F) ~ 70°C (158°F)
Operating Voltage
  • 3.3V±5%

Performance

Sequential Read/Write (CrystalDiskMark)
  • 2 TB

    up to 3,500/2,700 MB/s

  • 1 TB

    up to 3,400/1,900 MB/s

  • 512 GB

    up to 3,300/2,100 MB/s

  • 256 GB

    up to 3,300/1,100 MB/s

4K Random Read/Write (IOmeter)
  • 2 TB

    up to 340,000/310,000 IOPS

  • 1 TB

    up to 300,000/340,000 IOPS

  • 512 GB

    up to 210,000/310,000 IOPS

  • 256 GB

    up to 210,000/290,000 IOPS

Terabytes Written (TBW)
  • 2 TB

    4,400 TBW

  • 1 TB

    2,200 TBW

  • 512 GB

    1,100 TBW

  • 256 GB

    550 TBW

Mean Time Between Failures (MTBF)2,000,000 hour(s)
Drive Writes Per Day (DWPD)1.2 (5 yrs)
Note
  • Speed may vary due to host hardware, software, usage, and storage capacity.
  • The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
  • Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.

Warranty

Certificate
  • CE/
  • FCC/
  • BSMI/
  • KC/
  • RCM
Warranty
  • Five-year Limited Warranty
Warranty Policy
  • Please click here for more information about the Transcend Warranty Policy.
  • Warranty does not apply when SSD Scope’s wear-out indicator displays 0% within the warranty coverage.

System Requirement

Operating System
  • Microsoft Windows 7 (additional driver required)
  • Microsoft Windows 8 (additional driver required)
  • Microsoft Windows 10
  • Linux Kernel 2.6.31 or later
Note
  • Systems for use with the PCIe M.2 SSD must have an M.2 connector with only an M key. B-key connectors are not compatible. Improper insertion may lead to damage. Please click here for more information.

Technology

S.M.A.R.T.
Advanced Garbage Collection
RAID Engine
LDPC Coding
DRAM Cache

Additional information
Weight1 kg
Dimensions2.2 × 0.4 × 8 cm
BrandTranscend
Storage Size512GB
Form FactorM.2 2280
InterfacePCIe Gen3
Drive TypeConsumer
