NITRO+ AMD Radeon™ RX 6900 XT SE
- GPU: Boost Clock: Up to 2365 MHz
- GPU: Boost Clock: Up to 2135 MHz
- Memory: 16GB/256 bit DDR6. 16 Gbps Effective
- Stream Processors: 5120
- RDNA™ 2 Architecture
- Ray Accelerator:80
- ARGB Fan
GPU |
AMD Radeon™ RX 6900 XT Graphics Card |
7nm GPU |
AMD RDNA™ 2 Architecture |
Engine Clock |
Boost Clock: Up to 2365 MHz |
Game Clock: Up to 2135 MHz |
Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads. |
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary. |
Stream Processors |
5120 |
Infinity Cache |
128MB |
Ray Accelerators |
80 |
Memory Size/Bus |
16GB GDDR6 |
Memory Clock |
16 Gbps Effective |
Displays |
Maximum 4 Displays |
Resolution |
HDMI™: 7680×4320 |
DisplayPort1.4: 7680×4320 |
Interface |
PCI-Express 4.0 |
Output |
1x HDMI |
3x DisplayPort |
BIOS Support |
Dual UEFI |
Game Index |
4K |
Sapphire Features |
Dual BIOS |
Max Boost |
TriXX Software Switch |
Premium Digital Power Design |
Fuse Protection |
Tri-X Cooling Technology |
Intelligent Fan Control |
Precision Fan Control |
Backplate with ARGB |
ARGB Fans |
Two-Ball Bearing Fans |
Hybrid Fan Blade |
Wave Fin Design |
V Shape Fin Design for GPU Cooling |
Integrated Cooling Module |
K6.5 Memory Pad |
TriXX Supported |
Fan Check |
Fan Quick Connect |
TriXX Boost |
NITRO Glow |
External RGB LED MB Synchronization |
AMD Features |
AMD RDNA™ 2 Gaming Architecture |
DirectX® 12 Ultimate |
Hardware Raytracing |
7nm GPU |
GDDR6 Memory |
PCI® Express 4.0 Support |
AMD FreeSync™ Technology |
DisplayPort™ 1.4 with DSC |
HDMI™ |
Video Streaming up to 8K |
Radeon™ VR Ready Premium |
AMD FidelityFX |
Radeon™ Image Sharpening |
Radeon™ Anti-Lag |
Radeon™ Software |
Game Driver Optimizations |
High Performance 4K Gaming |
Cooling |
3 Fans |
Form Factor |
2.7 slot, ATX |
Dimension: 310(L)X 134.3(W)X 55.3 (H)mm |
Power Consumption |
363W |
OS |
Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required |
*Does not support all features including but not limited to Hardware Raytracing |
System Requirement |
Minimum 850 Watt Power Supply |
2 x 8-pin + 1 x 6-pin Power Connector. |
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. |
Minimum 8GB of system memory. 16GB recommended. |
Sapphire rX6900XT Nitro+ Special edition – RDNA2 architecture with hardware raytracing , 3 slots required , with nitro glow ARGB LED + aluminum backplate – with fuse protection + Fan iC control + Black Diamond Choke 4 + 3x ARGB fan with double-ball bearing + quad copper heatpipes + black polymer cap + nitro fan check, quick connect, cooltech, freeflow, boost + FRTC (frame rate target control) + Intelligent Fan Control III + dual bios – support liquidVR + XConnect ( external GPU solution for NB ) + eyefinity + Freesync technology + XDMA CrossFire ( no external connectors required ) + HDR , 7nm , Pci-E 4.0 16x , 16Gb 256bit GDDR6 ( 512Gb/sec memory transfer ) , 128RoPs ; 23040 GigaFLoPs, 288 GPexels/Sec , 720GT/s texture fill rate , 5120 stream processors , 320x texture unit , core clock : 2135/2365 mhz ; memory : 16000mhz , 3x DisplayPort 1.4 – require 2x8pin power connector
