Asus TUF GAMING Z690-PLUS WIFI D4 – LGA1700
R5,900 Incl VAT
Pay R5,723 When paying via EFT at checkout.
Supplier out of stock
This product is currently sold out.
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
- Intel® LGA 1700 socket: Ready for 12th Gen Intel Core™ processors
- Enhanced power solution: 14+1 DrMOS, six-layer PCB, ProCool sockets, alloy chokes and durable capacitors for stable power delivery
- Next-gen connectivity: PCIe® 5.0, USB 3.2 Gen2x2 Type-C®, front USB 3.2 Gen 2 Type-C, Thunderbolt™ 4 header support
- Made for online gaming: WiFi 6, Intel 2.5 Gb Ethernet and TUF LANGuard
- Two-way AI Noise-Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences
- Comprehensive cooling: Enlarged VRM heatsink, PCH fanless heatsink, M.2 heatsinks, hybrid fan headers and Fan Xpert 4 utility in Armoury Crate
- Outshine RGB Aura Effect: Stylish edge and PCH lighting design, addressable RGB headers and RGB strip header support
| Chipset | Intel Z690 |
| CPU Socket | LGA 1700 |
| USB | 1 x USB 3.2 Gen 2×2 Type-C 2 x USB 3.1 / USB 3.2 Gen 2 Type-A 1 x USB 3.1 / USB 3.2 Gen 1 Type-C 4 x USB 3.1 / USB 3.2 Gen 1 Type-A |
| Display | 1 x DisplayPort 1 x HDMI |
| Audio | 5 x 3.5 mm 1 x S/PDIF |
| Ethernet / Controller | 1 x Intel 2.5Gigabit |
| Wi-Fi Antenna | 2 x Connector |
| Memory Slots | 4 x 288-Pin |
| Memory Support | DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4600, 4800, 5000, 5133, 5333 MHz |
| Maximum Capacity | 128 GB |
| Channel Architecture | Dual Channel |
| ECC Support | Non-ECC Unbuffered |
| SATA | 4 x SATA III |
| M.2 | 2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4) 1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4) 1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4, SATA (Unspecified)) |
| U.2 | None |
| Optane Memory Support | Yes |
| RAID Support | RAID 0, 1, 5 (M.2) RAID 0, 1, 5, 10 (SATA) |
| Expansion Slots | 1 x PCIe 5.0 x16 1 x PCIe 3.0 x16 1 x PCIe 3.0 x4 1 x PCIe 4.0 x1 |
| USB | 1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port) 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port) 2 x USB 2.0 Header (Supports 4 USB Type-A Port) |
| Multi-GPU Support | None |
| Air Cooling | 1 x 4-Pin CPU 1 x 4-Pin Assistant 4 x 3-Pin Chassis |
| Liquid Cooling | 1 x 4-Pin Pump |
| Power Connectors | 1 x 24-Pin Mainboard 1 x 8-Pin ATX 1 x 4-Pin ATX |
| Security | Chassis Intrusion |
| LED Header | 4 x RGB |
| Audio | None |
| Diagnostics | Clear CMOS |
| Add-On | 1 x Thunderbolt Card Header |
| Legacy | 1 x Serial |
| ROM | 192 Mb |
| I/O Connection Headers | AAFP, USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2 |
| Audio Codec | Realtek (7.1-Channel) |
| Bluetooth | 5.2 |
| Wi-Fi | Wi-Fi 6 (802.11ax) |
| Supported Operating Systems | Windows 11 (64-Bit) Windows 10 (64-Bit) |
| Form Factor | ATX |
| Dimensions | 9.2 x 12″ / 23.4 x 30.5 cm |
| Weight | 1.96 kg |
|---|---|
| Dimensions | 33.8 × 28.7 × 7.1 cm |
| Brand | Asus |
| Socket | LGA 1700 |
| CPU Support | Intel 12ᵗʰ Generation, Intel 13th Generation, Intel 14th Generation |
| Chipset Manufacture | Intel |
| Chipset Model | Intel Z690 |
| Form Factor | ATX |
| Memory Slots Available | 4 Slots |
| Memory Type | Desktop DDR4 |
| On-Board WiFi | Yes |
| Reverse Connectors | No |
| GPU High Powered Connector | No |
| Windows Compatibility | Windows 10, Windows 11 ( Possibly Requires TPM ) |
| Colour | Black |
