DA500 is certified with 80 Plus Bronze with up to 85% electrical efficiency enabling lower heat generation and lower operation cost. Outstanding and stable performance makes it one of the ideal choices for multi-purpose usage.
Features:
-Compliant with Intel ATX12V V2.4
-Integrated Active PFC + PWM Combo Controller
-80 PLUS Bronze certified, achieve up to 85% efficiency
-120mm silent fan with temperature control function
-Longer cable design for enhancing cable management
-Support Multi-Way SLI / CrossFire + Multi-Core CPUs
-High reliability with at least 100,000 hour MTBF
Specifications:
-Model: DA500
-Type: ATX 12V V2.4
-Product Dimension: 150(W) x 140(L) x 86(H) mm
-Output Capacity: 500W
-Input Voltage: 100~240V
-Input Current: 8A
-Input Frequency Range: 45~60Hz
-Fan Size: 120mm Black Fan
-PFC: Active PFC (>0.99)
-Power Good Signal: 100-500ms
-Hold Up Time: >16ms
-Efficiency: 85% Under Typical Load
-Protection: OVP / UVP /SCP / OPP
-Operation Temperature: 0~40 C
-Regulatory: CE / FCC / CCC / CB / EAC / TUV
-MTBF: 100,000 Hours
Cable Connectors:
-Main Power Connector (24Pin) x1
-Main EPS 12V Connector 8(4+4)Pin x1
-PCI-E (6+2)Pin x2
-SATAx3 + 4pin Peripheralx1
-4pin Peripheralx2 + SATAx2
Package Specs:
-Weight: 1.6kg
-Dimensions: (L)27 x (W)10.5 x (H)18.5
What’s in the box:
-DA500N 500W 80+ Bronze PSU x 1
