MWE 450 White 230V – V2
80 PLUS Standard 230V EU Certified Power Supply
80 PLUS Standard 230V EU Certified
120mm HDB Fan
DC-to-DC Technology
Single +12V Rail
Flat Black Cables
Cooler Master MWE 450W ATX PSU |
ATX (1), PCI-E (2), 4-Pin Peripheral (3), SATA (6), Floppy (1) |
Flat Black Cables | Non Modular |
Product Code: MPE-4501-ACABW-EU
Product colour | Black |
---|---|
Number of fans | 1 |
Cooling type | Active |
Fan diameter | 120 |
Fan speed | 0 – 1500 |
Weight & dimensions
Width | 150 |
---|---|
Weight | 1337 |
Depth | 140 |
Height | 86 |
Packaging data
Package type | Box |
---|---|
Package width | 190 |
Package depth | 245 |
Package height | 110 |
Package weight | 1375 |
Operational conditions
Operating temperature (T-T) | 0 – 40 |
---|
Performance
80 PLUS certification | 80 PLUS |
---|---|
Mean time between failures (MTBF) | 100000 |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX version | 2.52 |
Certification | CCC, CE, TUV-RH, EAC, RCM, cTUVus, FCC, BSMI, KC, CB |
Bearing technology | HDB |
Supported motherboard form factors | ATX |
Power
AC input voltage | 200 – 240 |
---|---|
AC input frequency | 50/60 |
Input current | 4 |
Power protection features | Over power,Over voltage,Overheating,Short circuit,Under voltage |
Total power | 450 |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 100 |
Combined power (+12V) | 444 |
Combined power (+5V) | 100 |
Combined power (-12V) | 3.6 |
Combined power (+5Vsb) | 15 |
Max output current (+3.3V) | 15 |
Max output current (+12V) | 37 |
Max output current (+5V) | 15 |
Max output current (-12V) | 0.3 |
Max output current (+5Vsb) | 3 |
Efficiency | 85 |
Hold time | 14 |
Power Good signal delay range | 100 – 500 |
Logistics data
Quantity per pallet | 32 |
---|---|
Master (outer) case width | 260 |
Master (outer) case length | 570 |
Master (outer) case height | 215 |
Quantity per master (outer) case | 5 |
Ports & interfaces
Peripheral (Molex) power connectors (4-pin) | 3 |
---|---|
Number of SATA power connectors | 6 |
Motherboard power connector | 24-pin ATX |
PCI Express power connectors (6+2 pin) | 2 |
CPU power connector (4+4 pin) | Y |
Other features
Noise level (silent mode, <30%) | 11.18 |
---|---|
Noise level (quiet mode, 50%) | 17.1 |
Noise level (full-load mode, 100%) | 29.5 |
