The MasterBox NR600P is a workstation powerhouse that can configure to a wide range of professions. SSI-EEB support, a professional-grade I/O panel, and unrivaled cooling capabilities make the MasterBox the most functionally adaptive E-ATX case for creatives & professionals.
Features:
-Fine Mesh design on the front panel
-Dual CPU M/Bs are supported (SSI-CEB compatible)
-Dual Hot Swap Bays
-Two pre-installed 140mm fans
-Adaptive Storage Support
-Versatile Cooling Options
-Pre-installed I/O cable sleeve
-Integrated USB3.0 SD Card reader on I/O panel
Specifications:
-Exterior Color: Black
-Materials: Exterior: Mesh, Steel, Plastic / Left Side Panel: Steel
-Motherboard Support: Mini-ITX, Micro-ATX, ATX, SSI CEB, E-ATX, SSI-EEB
-Expansion Slots: 7
Drive Bays:
-3.5″ HDD: 1
-2.5/3.5″ Combo Cages: 2
-2.5/3.5″ Hot swap bays: 2 (toolfree)
-2.5″ SSD: 4
I/O Panel:
-USB Ports: 1x USB3.2 Gen 1 Type-C / 2x USB3.2 Gen 1 Type-A
-Audio In/Out: 1x 3.5mm Headset Jack (Audio+Mic)
-Card Reader: 1x SD/MMC USB3.0 Card Reader
Pre-Installed Fans:
-Front: 2x 140mm DC Fan
-Rear: 1x 120mm DC Fan
Fan Support:
-Top: 3x 120mm / 2x 140mm
-Front: 2x 120mm / 2x 140mm
-Rear: 1x 120mm
Radiator Support:
-Top: 120 / 140 / 240 / 280 / 360mm (maximum thickness clearance 43mm)
-Front: 120 / 140 / 240 / 280mm (*required repositioning of storage cage)
-Rear: 120mm
Clearance:
-CPU Cooler: 171mm
-Power Supply: 276mm (Max) / 180mm (Recommended)
-Graphics Card: 410mm
-Cable Routing – Behind MB Tray: 27~29mm
-Dust Filters: Front, Top, Bottom
-Power Supply Support: Bottom Mount, ATX
Package Specs:
-Weight: 8.5kg
-Dimensions: 56*31.2*60.4cm
In the Box:
-NR600P E-ATX Chassis x 1
-140mm Case Fan x 2
-120 Case Fan x 1
